When engineers face the challenge of integrating 4...20 mA loop-powered transmitters in Zone 1 hazardous areas, signal integrity and safety compliance become critical. The ABB AI930S HART analog input module, part of the S900 I/O system, provides a robust solution designed for such demanding environments.
Industry Trends in Hazardous Area I/O
The push for digitalization in process industries drives demand for I/O systems that combine safety with advanced diagnostics. The AI930S addresses this need by offering HART communication over PROFIBUS DP, enabling cyclic HART variables and extended diagnostics without compromising intrinsic safety. This aligns with Industry 4.0 goals for data-rich field devices.
Introducing the AI930S
The AI930S is a 4-channel analog input module from ABB's S900 I/O series, specifically designed for Zone 1 hazardous area installation. It powers and reads 4...20 mA loop-powered 2-wire transmitters, supporting HART frame transmission via the fieldbus. With ATEX Zone 1 certification and intrinsic safety, it connects safely to field devices in Zone 0, Zone 1, or Zone 2.
Technical Specifications and Performance
The module operates within an ambient temperature range of -20 °C to 60 °C and withstands relative humidity up to 93% at 40°C. Its compact dimensions—20 mm wide, 104 mm deep, and 104 mm high—allow dense installation in space-constrained cabinets. Weighing only 0.14 kg, the AI930S includes electrical isolation between input/bus and input/power, plus short and break detection for reliable operation.
Real-World Application Example
In a typical chemical processing plant, engineers use the AI930S to monitor pressure and temperature from intrinsically safe transmitters in Zone 1 areas. The module's hot swap functionality allows replacement without interrupting primary voltage, minimizing downtime during maintenance. Its G3 coating for corrosive atmospheres ensures long-term reliability in harsh environments.
Integration with Existing Networks
The AI930S communicates via PROFIBUS DP, a standard fieldbus for process automation. It integrates seamlessly with ABB control systems and third-party controllers supporting PROFIBUS DP. The module supports hot configuration in run and excellent diagnostics via FDT/DTM, simplifying setup and troubleshooting.
Frequently Asked Questions About the AI930S
What is the signal type supported by the AI930S?
The AI930S supports 4...20 mA analog input signals, specifically for loop-powered 2-wire transmitters. It also transmits HART frames via the fieldbus for additional process data.
Can the AI930S be used in Zone 0 areas?
The AI930S itself is designed for installation in Zone 1 hazardous areas. However, it can connect to intrinsically safe field devices installed in Zone 2, Zone 1, or Zone 0, as per the provided specifications.
Does the AI930S support redundancy?
No, the AI930S does not support redundancy. The S900 system offers redundancy for power and communication, but this specific analog input module is non-redundant.
