CtrlTechDaily reports that the Allen-Bradley 2094-BC02-M02-M Integrated Axis Power Module (IAM) is now available for industrial automation applications. This module, part of the Allen-Bradley 2097 series, combines an inverter and converter section in a single unit. It requires one control module for operation, simplifying system design and reducing cabinet space.
The 2094-BC02-M02-M delivers reliable power conversion for multi-axis motion control systems. Its integrated design helps engineers streamline installation and maintenance in demanding manufacturing environments.
Key Features
The 2094-BC02-M02-M operates at a nominal drive voltage of 360-480 Volts (3 Phase) with a voltage rating of 400/460VAC. This wide input range ensures compatibility with global industrial power systems. The converter section outputs 15kW, while the inverter section provides 72 Watts, supporting a range of servo motor loads.
The module delivers an output current of 15 A (0-pk) inverter current, suitable for medium-power motion axes. Its power dissipation ranges from 36-75 Watts, with heat dissipation of 44 W at 20% for the converter section and 72 W at 40% for the inverter section. These thermal characteristics enable efficient operation within standard enclosures.
The 2094-BC02-M02-M features a maximum bus capacitance of 8955 Microfarads, providing stable DC bus voltage for consistent motor performance. Its compact dimensions of 4.9 x 11.9 x 13.2 in (125 x 302 x 336 mm) and weight of 13.0 lbs (5.90 kg) allow flexible mounting in control cabinets.
Technical Specifications
The operating temperature range of 32-122 F (0-50 C) ensures reliable performance in typical industrial environments. The module requires an installation clearance of 80 mm (3.10 in.) and a minimum enclosure depth of 302 mm (11.9 in.) for proper airflow and maintenance access.
For control input protection, the 2094-BC02-M02-M uses a FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A) fuse. This specification helps engineers select appropriate branch circuit protection. The module's wattage rating of 6.6 kWatts reflects its total power handling capability under typical operating conditions.
Applications
The 2094-BC02-M02-M suits multi-axis motion control applications in packaging machinery. Its 15kW converter power and 15A inverter current support synchronized servo drives for film wrapping, cartoning, and labeling systems. The integrated design reduces wiring complexity and improves system reliability.
Material handling systems benefit from the module's robust power delivery. Conveyor lines, palletizers, and automated storage systems can use the 2094-BC02-M02-M to drive multiple axes with consistent torque and speed control. The 460VAC input matches common industrial power distribution.
Assembly lines in automotive and electronics manufacturing also leverage this module. The integrated axis power module simplifies cabinet layout and reduces component count, leading to faster commissioning and easier troubleshooting.
Availability
The Allen-Bradley 2094-BC02-M02-M is available now through CtrlTechDaily. We maintain stock to support quick delivery for your projects. Contact CtrlTechDaily for pricing and availability. Our team provides technical support to help you integrate this module into your automation system.
Frequently Asked Questions
What is the lead time for the 2094-BC02-M02-M?
CtrlTechDaily typically ships the 2094-BC02-M02-M within 1-2 business days for in-stock units. We maintain inventory to meet urgent project deadlines. Contact our sales team for current lead times on larger quantities.
Does the 2094-BC02-M02-M come with a warranty?
Yes, the Allen-Bradley 2094-BC02-M02-M includes a standard manufacturer warranty from Rockwell Automation. CtrlTechDaily also offers extended support options. Contact us for warranty details and after-sales service coverage.
What are the compatible systems for the 2094-BC02-M02-M?
The 2094-BC02-M02-M integrates with Allen-Bradley Kinetix 6000 and 6200 servo drive systems. It requires one control module, such as the 2094-EN02M or similar. The module works with 360-480 Volt 3-phase power systems and supports standard motion control networks.
