Introduction
CtrlTechDaily reports that the Allen-Bradley 2097-V33PR5 Kinetix 300 EtherNet/IP Indexing Servo Drive is now available for industrial automation applications. This servo drive delivers 2.0 kW continuous power and 11.3 A continuous output current. It supports single-phase or three-phase AC input from 80 to 264 VAC. The drive integrates EtherNet/IP communication for seamless connectivity in modern manufacturing environments. Its compact design and robust features make it a valuable addition to precision motion control systems.
Key Features
The 2097-V33PR5 includes Safe Torque-Off (STO) functionality certified to ISO 13849-1 PLd/SIL2 levels. This safety feature prevents unintentional motor rotation during emergencies, allowing maintenance tasks without disconnecting power. It enhances operator safety and reduces downtime. The drive supports five different indexing types and 32 index positions for flexible position control. It executes S-Curve and trapezoidal motion profiles to optimize acceleration and deceleration. Smart Motor Technology automatically identifies connected TL-Series and MP-Series motors, reducing commissioning time. The drive also provides master gearing, analog input control, and step/direction control modes.
Technical Specifications
The 2097-V33PR5 operates on 80-132VAC single-phase or 80-264VAC single-phase/three-phase input at 48-62 Hz. Continuous output current is 8.0 A RMS (11.3 A 0-peak), with peak output of 24.0 A RMS (33.9 A 0-peak). Power dissipation is 67 watts, requiring proper enclosure ventilation with minimum clearances of 3 mm on sides and 25 mm bottom/rear. The drive dimensions are 9.37 x 7.29 x 3.72 inches (238 x 185 x 94.0 mm) and weight is 4.4 lbs (2.0 kg). Operating temperature range is 32-104°F (0-40°C). These specifications suit applications requiring precise torque and speed control in confined spaces.
Applications
The 2097-V33PR5 excels in packaging machinery, material handling systems, and assembly lines. In packaging, it provides accurate indexing for fill-and-seal operations. For material handling, it controls conveyor belts and robotic actuators with high repeatability. In assembly lines, it positions components precisely using indexing and PTO commands. The drive also supports linear thruster actuators and ball screw stages for custom automation tasks.
Availability
The Allen-Bradley 2097-V33PR5 is in stock at CtrlTechDaily with fast shipping options. We offer competitive pricing and technical support for integration. Contact CtrlTechDaily for pricing and availability.
Frequently Asked Questions
What is the lead time for the 2097-V33PR5?
CtrlTechDaily maintains inventory of the 2097-V33PR5 for quick delivery. Lead time typically ranges from 1 to 3 business days depending on order volume. Contact our sales team for exact lead times and expedited shipping options.
Does the 2097-V33PR5 come with a warranty?
Yes, the 2097-V33PR5 includes a standard manufacturer warranty from Rockwell Automation. Warranty covers defects in materials and workmanship under normal use. CtrlTechDaily provides additional support for warranty claims and replacement procedures.
What are the compatible systems for the 2097-V33PR5?
The 2097-V33PR5 integrates with Allen-Bradley ControlLogix and CompactLogix controllers via EtherNet/IP. It is compatible with MP-Series motors such as MPL-A320H and TL-Series motors like TLY-A2530P. The drive also works with linear thruster actuators and ball screw stages. Recommended protection includes Bussmann KTK-R-30 fuse and 1489-A1C300 circuit breaker for single-phase, or KTK-R-20 and 1489-A3C200 for three-phase.
