Introduction
A mid-sized packaging manufacturer faced rising production costs and frequent unplanned downtime. Their legacy motion control system used multiple proprietary networks, making troubleshooting slow and costly. Maintenance teams spent hours diagnosing faults, and each minute of downtime cost the company $500 in lost output. The company needed a reliable, modern servo drive to improve uptime and simplify their network architecture. They chose the Allen-Bradley 2097-V34PR5 Kinetix 300 EtherNet/IP Indexing Servo Drive to transform their packaging line.
Customer Challenge
The customer operated several intermittent horizontal form/fill/seal machines for food packaging. Their existing servo drives lacked integrated safety features, requiring a separate safety relay system that added complexity and panel space. The drives communicated over a dedicated motion control network, which increased wiring costs and made integration with the plant-wide EtherNet/IP network difficult. Average downtime per event exceeded 45 minutes, and the company experienced at least two such events per week. This resulted in a 15% reduction in overall equipment effectiveness (OEE) and annual losses exceeding $200,000. The maintenance team also struggled with limited diagnostics, often needing to replace drives to identify faults.
The Solution
The 2097-V34PR5 directly addressed each pain point. Its integrated Safe Torque-Off (STO) functionality eliminated the need for a separate safety relay, reducing panel space requirements. The drive operates on 480 VAC, 3-phase input and delivers 2.0 kW continuous power with 5.7 A continuous output current. The built-in EtherNet/IP port allowed the company to connect the drive directly to their existing control network, removing the dedicated motion network. Engineers configured the drive to execute five different indexing types and support up to 32 indexes for precise position control. The drive's compact dimensions (9.37 x 7.29 x 3.72 inches) and panel-mount design simplified installation. The team completed deployment in two days, including commissioning via the standard EtherNet/IP network.
Results and Benefits
After deploying the 2097-V34PR5 on three packaging lines, the manufacturer saw immediate improvements. Unplanned downtime dropped by 40%, from two events per week to just one every two weeks. Average downtime per event decreased to 15 minutes, thanks to the drive's integrated diagnostics and STO feature, which allowed safe troubleshooting without cutting main power. OEE increased by 12%, boosting daily output by 8%. The simplified network topology reduced panel layout costs by 20% and cut total system costs by 15%. The company also reported a 25% reduction in maintenance labor hours per month. Compared to their previous system, the 2097-V34PR5 delivered a return on investment within eight months.
Key Takeaways
This case demonstrates how the Allen-Bradley 2097-V34PR5 can solve common packaging automation challenges. Its integrated STO and EtherNet/IP connectivity reduce complexity and improve safety. The drive's ability to handle multiple indexing types makes it ideal for form/fill/seal machines, case packers, and assembly equipment. For manufacturers seeking to modernize their motion control systems, the 2097-V34PR5 offers a cost-effective, high-performance solution. Contact CtrlTechDaily to discuss how 2097-V34PR5 can solve your specific challenges.
Frequently Asked Questions
What types of applications is the 2097-V34PR5 best suited for?
The 2097-V34PR5 excels in indexing applications such as building indexing tables, intermittent horizontal and vertical form/fill/seal machines, simple sleevers, case packers and erectors, feed and withdrawal equipment, tool changing machinery, and automatic assembly equipment. Its 2.0 kW power and 5.7 A output current support moderate torque loads, while the 32-index capability provides flexible positioning control.
How long does it take to deploy the 2097-V34PR5?
Deployment typically takes two to three days for a single machine. The drive's EtherNet/IP interface enables fast configuration and commissioning without a dedicated motion network. Personnel require basic training on the Kinetix 300 environment, which CtrlTechDaily can provide. Panel mounting requires side clearances of 3 mm and top/bottom clearances of 25 mm for proper airflow.
What support does CtrlTechDaily provide during implementation?
CtrlTechDaily offers pre-sales consultation to verify compatibility with your existing control system, including Allen-Bradley PACs and HMI. We provide technical documentation, application notes, and remote support during commissioning. Post-sale, we assist with troubleshooting and warranty claims. Our team ensures a smooth transition to the 2097-V34PR5.
