Introduction
CtrlTechDaily reports that the Allen-Bradley 2097-V34PR5 Kinetix 300 EtherNet/IP Indexing Servo Drive is now available for industrial automation applications. This servo drive operates with an input voltage of 480 VAC, 3-phase, and delivers a continuous output current of 5.7 A with an output power of 2.0 kW. It is part of the Kinetix 300 series, designed for cost-effective, single-axis motion control.
The 2097-V34PR5 integrates Safe Torque-Off (STO) functionality, enhancing safety during maintenance and troubleshooting. With a built-in EtherNet/IP interface, it simplifies connectivity to modern industrial networks, reducing the need for dedicated motion control networks. This drive is ideal for applications requiring precise indexing and position control.
Key Features
The 2097-V34PR5 features integrated Safe Torque-Off (STO), which allows safe machine access without removing power from the entire system. This reduces downtime and improves productivity. The drive supports multiple feedback devices, including SICK-Stegmann Hiperface, Generic TTL Incremental, and Tamagawa 17 bit Serial, providing flexibility for various motor types.
It includes one Ethernet communication port for seamless integration with EtherNet/IP networks. The drive can execute up to 32 indexes with five different indexing types, making it suitable for applications like indexing tables, form/fill/seal machines, and automatic assembly equipment. Its compact dimensions of 9.37 x 7.29 x 3.72 inches (238 x 185 x 94.0 mm) and weight of 4.4 lbs (2.0 kg) simplify panel mounting.
Technical Specifications
The 2097-V34PR5 operates with an input voltage of 480 VAC, 3-phase, and an input frequency range of 48 to 62 Hz. It delivers a continuous output current of 5.7 A (0-peak) and an output power of 2.0 kW. The drive dissipates 58 Watts of power and has a torque value of 5.0-7.0 lb*in (0.56-0.79 N*m).
It requires a minimum mounting clearance of 3 mm (0.12 in.) on the sides and 25.0 mm (1.0 in.) on the top and bottom for proper airflow. The operating temperature range is 32-104 F (0-40 C). The drive does not include an integrated AC line filter or 120 Volt Doubler Mode. It is panel mountable and includes a single-ended thermostat that detects faults when resistance exceeds 10 kΩ.
Applications
The 2097-V34PR5 is well-suited for packaging machinery, such as intermittent horizontal and vertical form/fill/seal machines, simple sleevers, case packers, and erectors. Its indexing capabilities make it ideal for building indexing tables and feed and withdrawal equipment in automated assembly lines.
It also supports tool changing machinery and automatic assembly equipment, where precise position control and safety are critical. The drive's EtherNet/IP connectivity allows integration with HMIs, I/O, and programmable automation controllers (PACs), streamlining overall system architecture and reducing panel layout requirements.
Availability
The Allen-Bradley 2097-V34PR5 is available through CtrlTechDaily with fast shipping and technical support. Contact CtrlTechDaily for pricing and availability. Our team provides pre-sales consultation and after-sales service to ensure successful deployment in your automation projects.
Frequently Asked Questions
What is the lead time for the 2097-V34PR5?
Lead time varies based on inventory levels, but CtrlTechDaily typically maintains stock for quick shipment. Contact us directly for current lead times and availability. We prioritize fast delivery to minimize project delays.
Does the 2097-V34PR5 come with a warranty?
Yes, the 2097-V34PR5 comes with a manufacturer warranty from Rockwell Automation. CtrlTechDaily provides additional after-sales support to assist with any issues during the warranty period. Contact our team for specific warranty terms and coverage details.
What are the compatible systems for the 2097-V34PR5?
The 2097-V34PR5 integrates with EtherNet/IP networks and supports feedback devices such as SICK-Stegmann Hiperface, Generic TTL Incremental, and Tamagawa 17 bit Serial encoders. It is compatible with Rockwell Automation controllers and other EtherNet/IP-enabled devices. For specific compatibility questions, consult the product manual or contact CtrlTechDaily technical support.
