Product Summary
The VE6049M01 is an 8-port expansion module from DeltaV, designed for the RM100 chassis. It offers a 100-meter cable length for flexible system layout. This module consumes just 2W of power for energy efficiency. Its compact size and light weight simplify installation in tight spaces. The device supports reliable communication across your distributed control system. It is a critical component for expanding network connectivity.
Theme Option A: Product Procurement & Buyer Guide
Technical Specifications for Informed Selection
The VE6049M01 gives procurement managers a clear, reliable option for system expansion. This module uses only 2W of power, which reduces overall energy costs. It outputs 7 Btu (IT) h of heat, requiring minimal cooling. The unit operates within a temperature range of 0°C to +50°C. It also withstands storage temperatures from -20°C to +85°C. This tolerance ensures safe transport and long shelf life. The module handles non-condensing humidity from 10% to 95%. Such a wide range suits harsh industrial environments perfectly. You can integrate this module into existing DeltaV architectures easily. It mounts directly into a media module slot within the RM100 chassis. This design simplifies field replacement and reduces downtime significantly.
Mechanical and Environmental Resilience
The VE6049M01 measures just 138 mm x 90 mm x 42 mm. This small footprint saves valuable space inside your control cabinet. The module weighs only 0.21 kg, making it easy to handle. Its IP20 protection class guards against solid objects larger than 12mm. This rating is ideal for clean, indoor control room environments. The module uses a standard 100-meter twisted pair cable for connectivity. This length allows for flexible placement away from the main controller. You can rely on this component for consistent, long-term performance.
Theme Option B: Step-by-Step User & Installation Guide
Mechanical Mounting Procedure
Begin by ensuring the RM100 chassis is properly mounted and powered down. Locate an available media module slot for the VE6049M01 insertion. Align the module’s guide rails with the chassis slot tracks carefully. Gently slide the module into the slot until it clicks securely. The unit’s lightweight design makes this one-handed installation possible. Tighten any retaining screws to prevent vibration-induced disconnection. Verify the module sits flush with the chassis face for proper grounding.
Electrical Wiring and Deployment
Connect the 100-meter TP cable to the designated port on the VE6049M01. Ensure the cable is routed away from high-voltage power lines. Power consumption is only 2W, so a standard power supply works fine. The module will draw power directly from the backplane of the chassis. No external power supply unit is necessary for this specific component. After wiring, power up the chassis and check the module’s status LEDs. The system will automatically recognize the new expansion module.
Logistics & Standard Packaging Details
- One (1) DeltaV VE6049M01 8-port Expansion Module
- One (1) 100-meter Twisted Pair (TP) cable
- Standard anti-static packaging for safe transport
- Quick-start installation guide
Express delivery shipping is available via FedEx, UPS, and DHL.
