Product Summary
The Emerson SE4050E1C0 8-Wide I/O Interface Carrier simplifies power distribution for S-series subsystems. This carrier supports 8 I/O modules and uses only 24V DC bulk power. It includes 8 power buss plugs, a carrier shield bar, and a single 1.1m extender cable for flexible system layouts.
Theme Option B: Step-by-Step User & Installation Guide
Mechanical Mounting on DIN Rail
You can mount the carrier to standard T-type DIN rail quickly. The unit features integrated latches that require no tools for installation. Simply snap the carrier onto the rail and slide adjacent carriers together to engage the bus connector. You can release the latches using a standard blade screwdriver for easy reconfiguration.
Power Connection Architecture
The system uses a redesigned internal 24V DC bus. This bus is divided into primary and secondary power distribution. Primary power goes to odd-numbered slots, while redundant power goes to even-numbered slots. Use the included Power Buss Plugs to connect each card to the internal bus. Alternatively, you can power each card individually using separate Power Terminal Plugs.
Carrier Extender Cable Deployment
This model includes a single 1.1m (43 in) carrier extender cable. Use this cable to physically separate carriers while maintaining electrical continuity. This feature allows you to place additional power carriers anywhere along the bus. The upgraded bus connectors also support additional 12V DC power to the I/O cards for enhanced flexibility.
Electrical Specifications for Deployment
The backplane current rating is 15 Amps for horizontal I/O carriers. Each Power Buss Plug has a fused rating of 5 Amps. The primary and secondary 24V DC busses distribute 12 Amps per bus with a maximum of 3 Amps per card. The Power Terminal Plug supports up to 12 Amps for individually powered modules.
Environmental Installation Considerations
The carrier operates reliably in temperatures from -40 to 70°C (-40 to 158 °F). It stores safely between -40 to 85°C (-40 to 185 °F). The unit handles humidity levels from 5 to 95% non-condensing. It also withstands airborne contaminants per ISA-S71.04-1985 Class G3 with conformal coating. The protection rating is IP 20 for indoor use.
Vibration and Shock Tolerance
The carrier withstands shock loads of 10 g with a ½-sine wave for 11 ms. It handles vibration of 1 mm peak-to-peak from 5 to 13.2 Hz. The unit also tolerates 0.7 g vibration from 13.2 to 150 Hz. These specifications ensure reliable operation in demanding industrial environments.
Logistics & Standard Packaging Details
- One Emerson SE4050E1C0 8-Wide I/O Interface Carrier
- Eight Power Buss Plugs for internal bus connection
- One Carrier Shield Bar for noise protection
- One Single Carrier Extender Cable (1.1m / 43 in)
- Express delivery shipping is available via FedEx, UPS, and DHL.
