Product Summary
The FR-T0400P temperature acquisition module from Flexem provides four precise input channels for industrial environments. This unit supports PT100, PT1000, Ni100, Ni1000, Cu50, and Cu100 sensors. Engineers gain accurate measurements across a wide temperature range from -200°C to 850°C. The module draws a maximum power of only 50mA at 5.0Vdc. Its slim 18mm width saves valuable space inside control cabinets.
Expert Technical Evaluation & Performance Review
This section offers a strict engineering critique of the FR-T0400P component. We base this analysis directly on the official technical specifications provided.
The module achieves a measurement accuracy of ±0.5% or ±1°C at a 25°C ambient temperature. The system selects whichever value is larger to ensure reliable data. This performance metric suits most general industrial monitoring tasks. You can trust this device for consistent thermal data logging.
The FR-T0400P supports a diverse array of sensor types. For PT100 sensors, the measurement range extends from -200°C to 850°C. The PT1000 variant covers a range from -200°C up to 600°C. Copper-based Cu50 and Cu100 sensors operate effectively between -50°C and 150°C. Nickel sensors like the Ni100 and Ni1000 function within a -60°C to 180°C window.
Engineers will appreciate the module's low power consumption. The device requires a maximum of 50mA at a 5.0Vdc supply voltage. This efficiency reduces the overall thermal load within a dense panel. It also simplifies your power supply budgeting during the design phase.
The mechanical dimensions measure 111 millimeters in height by 18 millimeters in width and 76 millimeters in depth. The total weight is a mere 65 grams. This lightweight and narrow profile allows for high-density mounting on standard DIN rails.
Deep-Dive Technical FAQ
This FAQ section answers three specific technical questions about the FR-T0400P module.
Question 1: Can the FR-T0400P handle both 2-wire and 4-wire RTD connections?
The provided specifications do not explicitly state the wiring configuration support. You must consult the official factory datasheet for this specific detail. Implementing a 4-wire connection typically yields the highest accuracy for RTD measurements. We recommend verifying this parameter before finalizing your system design.
Question 2: What is the exact impact of ambient temperature on measurement accuracy?
The stated accuracy of ±0.5% or ±1°C applies specifically at a 25°C ambient temperature. Operating the module outside this ideal temperature will likely introduce additional drift. You should factor this thermal coefficient into your error budget calculations. The datasheet will provide a specific drift curve for extreme environments.
Question 3: Does this module support any industrial communication protocols?
The provided knowledge base does not list any communication protocol support. The FR-T0400P appears to function as a dedicated analog input module. You will need a separate bus coupler or controller to integrate this data. Please refer to the Flexem system manual for compatible backplane options.
Logistics & Standard Packaging Details
We ship every FR-T0400P module in a secure, anti-static package. The standard package includes the following essential components:
- One Flexem FR-T0400P temperature acquisition module
- A quick-start installation guide with wiring diagrams
We offer express delivery shipping for all orders. You can select from FedEx, UPS, and DHL at checkout. This ensures fast and reliable delivery to your facility.
