The Allen-Bradley 1734-AENTR serves as the primary communication gateway. This module links your POINT I/O rack to the controller. It operates on the EtherNet/IP network with high reliability. The adapter supports ring, star, and tree network topologies. You can achieve transmission speeds of 10/100 Mbits/s. The module runs in either half or full-duplex mode. It requires a standard 24 Volts DC input power supply. This component mounts easily on a standard DIN rail. The operating temperature range spans -20 to 60 degrees Celsius. This robust design ensures performance in harsh industrial environments.
Theme Selection: Installation Guide & Technical Evaluation
Step-by-Step Installation for the 1734-AENTR
You must install this module on the leftmost position. This location establishes the primary network connection for the system. The 1734-AENTR transfers I/O data from the backplane. It communicates this data to the main controller over the network. Mount the adapter vertically on a standard DIN rail. Ensure the enclosure rating is open for proper airflow. The module weighs only 0.62 pounds for easy handling. Use Category 5 or Category 6 twisted pair cable. Connect using the two RJ-45 ports for pass-through. These ports function as embedded switches for network flexibility. Set the network IP address using the thumbwheel switches. You can also use the BOOT-P or DHCP utility. A static IP address prevents communication errors during power cycles. Dynamic addresses change every time you cycle the power. Use a static address to avoid unauthorized control or loss of control.
Expert Technical Performance Review
This adapter supports a maximum expansion I/O capacity of 63 modules. It also supports up to 31 direct connections simultaneously. The module consumes a maximum of 10.4 Watts at 28.8 Volts DC. This power efficiency reduces overall system heat generation. The input voltage rating is 24 Volts DC with reverse polarity protection. The isolation voltage is 50 Volts continuous for signal integrity. The communication rate auto-negotiates between 10 and 100 Mbits/s. This function ensures compatibility with existing network infrastructure. The module uses messages encapsulated within TCP/UDP/IP protocol. No network scheduling or routing tables are required for operation. The adapter supports simultaneous communication with multiple scanner modules. This feature allows for complex, multi-controller system architectures. The enclosure rating is open, so install it in a protected cabinet. The wide operating temperature range supports demanding continuous processes.
Logistics & Standard Packaging Details
- One Allen-Bradley 1734-AENTR POINT I/O Adapter Module
- Pen push thumbwheel switches for network address setting
- Standard product documentation and quick reference guide
- The module ships in anti-static protective packaging
