Product Summary
The Allen-Bradley 1747-C10 is a critical 6-foot programming cable for SLC 500 controllers. It uses an RJ-45 connector to ensure reliable data transfer. This cable supports both programming and communication peripheral devices. Use it as a direct replacement for your existing setup. It operates effectively in harsh industrial environments.
Why Choose the 1747-C10 for Your SLC 500 System?
This cable solves a key pain point for engineers and buyers. You need a reliable link between your controller and programming device. The 1747-C10 provides a stable, secure connection every time. It eliminates communication dropouts that waste valuable production time. Its 6-foot length offers flexibility for cabinet configurations.
The cable supports a wide operating temperature range. It functions reliably from 32 to 140 degrees Fahrenheit. This makes it suitable for factories with high ambient heat. The storage range is even more impressive. You can store it safely from -40 to 185 degrees Fahrenheit. This durability ensures a long service life in varied conditions.
Technical Specifications and Environmental Tolerances
This cable is designed for demanding industrial use. It withstands relative humidity levels from 5 to 95 percent. This performance holds true only without condensation present. The RJ-45 connector provides a standardized and robust interface. It connects easily to compatible SLC 500 peripherals.
You can use this cable with various programming devices. It also supports peripheral communication devices for your system. The manufacturer is Allen-Bradley, a trusted name in automation. This is a replacement cable for the SLC 500 controller series. It ensures your legacy system stays operational and efficient.
Installation and Usage Guide for the 1747-C10
Installing this cable is a straightforward process for any technician. First, verify your controller is powered down for safety. Then, insert the RJ-45 connector into the correct port. Ensure the clip clicks firmly into place to secure the connection. Route the cable away from high-voltage power lines.
Connect the other end to your programming terminal or device. Power up the SLC 500 controller and your programming software. The system should recognize the cable immediately. This plug-and-play design minimizes downtime during setup. Always inspect the cable for cuts or damage before use.
Logistics & Standard Packaging Details
- One (1) Allen-Bradley 1747-C10 programming cable
- Standard length of 6 feet with RJ-45 connectors
- Packaged in anti-static protective wrapping
- Ships in a durable cardboard box for transit safety
- Express delivery shipping is available via FedEx, UPS, and DHL
