The 1747-M15 memory adapter socket bridges your PROM programmer with your SLC 500 memory modules. This component ensures reliable flash memory programming for critical process backups. Engineers rely on this adapter to prevent costly program loss from battery failures.
Product Procurement & Buyer Guide
This section explains how the 1747-M15 solves key industrial pain points. It provides a secure interface for programming non-volatile memory.
The 1747-M15 adapter socket supports the 1747-M13 memory module. You must use a Series B 1747-M15 adapter to avoid damaging the memory module. A Series A adapter can cause permanent hardware failure.
This socket works with SLC 5/03, SLC 5/04, and SLC 5/05 processors. Each processor uses different communication protocols for your network. The SLC 5/05 uses standard Ethernet for high-speed data transfer.
The memory adapter holds a flash EEPROM unit with 65 kilobytes of capacity. This provides ample space for your control program and data tables. The program scan time is a fast 0.9 milliseconds.
Procurement managers must consider the physical dimensions of this unit. The socket measures 6 inches by 6 inches by 3 inches. It weighs only 2 pounds for easy handling.
The adapter operates in a relative humidity range of 5% to 95%. This tolerance ensures performance in diverse industrial environments. The operating temperature range is 0 to 60 degrees Celsius.
Storage conditions allow for temperatures between -40 and 85 degrees Celsius. The unit withstands an operating shock of 1 G at 5 to 2000 Hertz. These ratings confirm its durability for harsh factory floors.
Step-by-Step User & Installation Guide
Follow these steps to install and use the 1747-M15 adapter correctly. Proper handling prevents damage to sensitive electronic components.
First, ensure the controller is switched OFF before installation. This prevents undesired faults and protects the processor board. Never install or remove the module with power applied.
Second, handle the 1747-M15 adapter with care for electrostatic discharge. Always wear a grounded wrist strap when you touch the socket. Work in an environment free from static electricity.
Third, orient the 1747-M13 memory module correctly on the jumpers. Connect the jumper from A18 to the center pin. Improper jumper configuration can damage the memory module.
Fourth, fit the memory module into the 1747-M15 adapter socket. Then place the adapter into the ZIF socket on the PROM programmer. The zero insertion force design prevents pin damage.
Fifth, initiate a program burn to the EEPROM module from your computer. The user program loads automatically on every power cycle. This ensures your process always runs the correct code.
The connectors on the memory module are keyed for proper alignment. This prevents incorrect installation into the adapter socket. Always verify the orientation before applying force.
Logistics & Standard Packaging Details
- 1x Allen-Bradley 1747-M15 Memory Module Adapter Socket
- Standard anti-static packaging for safe transport
- Express delivery shipping is available via FedEx, UPS, and DHL
