Product Summary
The 1762-L24BWAR MicroLogix 1200 controller manages small to medium automation tasks. This unit combines an input power supply with embedded I/O. It operates on 120 to 240 Volts AC power. The controller offers 10 relay outputs for switching loads. It also provides 14 inputs for 24 Volt DC sensors.
Expert Technical Evaluation & Performance Review
The 1762-L24BWAR functions as a sink/source MicroLogix 1200 controller. This unit integrates a power supply with its I/O system. The controller accepts input power from 120 to 240V AC. This wide range simplifies global installation requirements.
The module features 10 standard 24V DC inputs. It also includes 4 fast 24V DC inputs for high-speed signals. These fast inputs operate at frequencies up to 1 kHz. The standard inputs handle frequencies from 0 to 20 Hertz.
Each input channel has precise current specifications. Inputs 0 to 3 require a minimum on-state current of 2.5 mA at 14V. Their nominal current is 7.3 mA at 24V DC. Inputs 4 and above need a minimum of 2 mA at 10V DC. Their nominal current measures 8.9 mA at 24V DC. All inputs have a maximum on-state current of 12 mA.
The controller drives 10 relay outputs at 24 Volts DC. Relays provide robust switching for inductive loads. The off-state voltage range sits between 0 and 5 Volts DC. The off-state leakage current stays at a minimum of 1.5 mA.
Product Procurement & Buyer Guide
Engineers choose this controller for its embedded I/O architecture. The 1762-L24BWAR combines power supply, inputs, and outputs into one unit. This design saves valuable panel space. The module measures just 3.5 x 4.33 x 3.43 inches.
The sensor supply has a common connection tied to chassis ground. Use this supply strictly for input devices like switches and sensors. Do not use it for output circuits to avoid ground loops.
A dedicated RS-232 port facilitates programming and HMI connections. This port supports DH Full-duplex applications only. It cannot initiate messages and has fixed communication parameters. Use this port for local operator interface tasks.
The total sensor current equals the sum of all connected device currents. Ensure your sensor load does not exceed the supply rating. This controller fits perfectly in machine control and conveyor systems.
Logistics & Standard Packaging Details
- One Allen-Bradley 1762-L24BWAR MicroLogix 1200 Controller
- Product documentation and installation manual
- Standard anti-static packaging for safe transit
We offer express delivery shipping via FedEx, UPS, and DHL. This ensures fast and reliable worldwide delivery. Order now for quick deployment in your facility.
