Product Summary
The Allen-Bradley 1762-L24BXBR is a compact and rugged programmable controller from the MicroLogix 1200 series. This device integrates 24 input and output points, including high-speed and FET options, for precise machine control. Its small footprint and flexible mounting make it ideal for space-constrained industrial applications. Engineers value its reliable 24VDC power supply and robust communications suite.
Why Choose the 1762-L24BXBR for Your Application?
The 1762-L24BXBR offers an excellent balance of power and size. This controller provides ten standard 24VDC inputs along with four fast inputs. These fast inputs capture signals up to 20 kHz for precise motion control. The output configuration includes five relay outputs, four standard FET outputs, and a dedicated high-speed FET channel. This mix allows you to drive both inductive loads and high-frequency devices directly.
Procurement managers appreciate the controller's built-in real-time clock. This feature enables time-based scheduling and event logging without extra modules. The device supports six expansion I/O modules to scale up to 96 total points. This flexibility allows a single controller to serve many different machine sizes. The unit also offers two trim potentiometers for simple local adjustments.
Installation Guide for the 1762-L24BXBR
Mounting this controller is straightforward with either DIN rail or panel hardware. The unit requires a clearance of only 50 mm on all sides. This small gap allows for dense panel layouts without complex ventilation. Always use a 24VDC power supply that can handle the 82 VA power draw.
The controller features two 8-pin mini-DIN communication ports. Use the front port for primary networking with HMI devices or supervisory systems. The side port is a dedicated programming interface for quick uploads and downloads. Supported protocols include DF1, DH-485, ASCII, and Modbus for broad compatibility.
Wire the relay outputs according to their rated contact loads of 10A. The relay outputs can handle both 24-125VDC and 120-240VAC circuits. The FET outputs are ideal for high-speed switching of DC loads. Connect the fast inputs to channels 0-3 to leverage their 0-20 kHz frequency acceptance. Standard inputs on higher channels can still capture signals up to 1 kHz.
Logistics & Standard Packaging Details
- One (1) Allen-Bradley 1762-L24BXBR MicroLogix 1200 programmable controller.
- Product dimensions: 90 mm height (104 mm with latch), 160 mm width, 87 mm depth.
- Shipping weight is approximately 2.4 pounds.
- Standard operating temperature range is 0 to 55 degrees Celsius.
- We ship this item via FedEx, UPS, and DHL for express delivery options.
