The Allen-Bradley 1763-L16AWA MicroLogix 1100 Programmable Controller delivers a powerful, compact industrial automation solution. This versatile controller integrates critical I/O and communication ports into a single, space-saving unit. It efficiently handles tasks for material handling, packaging, and general machinery control. You can rely on this Rockwell Automation product for robust performance in demanding environments.
Product Summary
The Allen-Bradley 1763-L16AWA MicroLogix 1100 Controller integrates ten 120V AC digital inputs, two 0-10V DC analog inputs, and six relay outputs. It features built-in Ethernet/IP and isolated RS-232/485 ports. This compact PLC offers an LCD display for local diagnostics and configuration.
Product Procurement & Buyer Guide for the 1763-L16AWA
Procurement managers need a controller that balances performance with cost-efficiency. The 1763-L16AWA fills this niche perfectly. Its 16-point count handles many small-scale machine control tasks. The controller requires an input power of 120 to 240 Volts AC. This wide range simplifies global integration for OEMs.
This PLC uses ten dedicated 120V AC digital inputs for high-voltage sensors. It also includes two analog inputs that accept a 0-10V DC signal. The analog data is stored as a 10-bit unsigned integer. This resolution is perfect for basic transmitters and transducers.
The six relay outputs handle loads up to 10 Amperes each. These outputs have a mechanical life of 10,000,000 cycles. You can switch loads from 120-240V AC up to 125V DC. This makes the 1763-L16AWA ideal for clutch/brake and position control applications.
The dual communication ports provide extreme flexibility for machine builders. The integrated Ethernet/IP port supports high-speed connectivity at 10/100 Mbps. The isolated RS-232/485 port allows peer-to-peer or multi-node network configurations. You can even program and monitor the controller over the network.
Deep-Dive Technical FAQ for the 1763-L16AWA
Question 1: How does the built-in LCD display assist with controller setup?
The LCD screen allows you to assign critical controller parameters locally. You can configure communication settings directly without needing a connected PC. This feature speeds up initial commissioning and on-site troubleshooting. It provides immediate access to status data and error information.
Question 2: What are the grounding requirements for the RS-232/485 port?
Devices connected to the RS-232/485 combo port must be floating. Alternatively, they must reference the controller ground. This requirement prevents ground loops and ensures reliable serial communication. Proper grounding is essential for stable industrial network performance.
Question 3: Can the 1763-L16AWA handle high-speed motor control applications?
The controller is designed for general industrial machinery and position control. Its relay outputs have a turn ON/OFF time of 10 milliseconds. For high-speed servo control, you may require a dedicated motion controller. The 1763-L16AWA excels at sequential logic and process control tasks.
Logistics & Standard Packaging Details
- One (1) Allen-Bradley MicroLogix 1100 1763-L16AWA Programmable Controller
- Product documentation and quick-start guide
- Standard industrial packaging for safe transit
- Express delivery shipping is available via FedEx, UPS, and DHL.
