Product Summary
The 1794-OB32P is a Rockwell Automation Flex I/O discrete output module. It delivers thirty-two individually protected 24V DC sourcing channels. This module controls actuators, relays, and indicators with high reliability. Its electronic fusing prevents damage from overloads and short circuits.
Theme A: Product Procurement & Buyer Guide
Why Choose the 1794-OB32P for Your System?
Procurement engineers need robust components for critical applications. The 1794-OB32P provides thirty-two outputs in a compact form factor. This design saves valuable panel space and reduces wiring complexity. You get a high channel count without sacrificing performance or protection.
Key Technical Specifications for Selection
This module delivers a total output current of 14.0 Amperes maximum. Channels 0 through 15 share a 6 Ampere limit. Channels 16 through 31 have an 8 Ampere limit. Each output handles up to 500 mA continuously. The module operates on a nominal 24V DC supply voltage.
Understanding Electronic Protection Features
The 1794-OB32P uses electronic fusing on every output channel. This feature eliminates the need for external fuses. It protects your wiring and connected loads from fault currents. The module automatically shuts down a faulty channel. This action prevents damage to the entire system.
Ensuring Compatibility with Terminal Bases
This module requires a compatible terminal base unit. You must use the 1794-TB32 or the 1794-TB32S base. These bases provide the wiring interface for field devices. Always verify your existing base model before purchasing. Using the correct base ensures a secure mechanical and electrical connection.
Application Versatility for Industrial Loads
The 1794-OB32P drives many standard 24V DC industrial loads. It controls indicating lights, buzzers, and horns effectively. It also switches relay coils and solenoid valves reliably. This versatility makes it a standard choice for automation projects. You can standardize your designs around this single module.
Logistics & Standard Packaging Details
- One (1) Allen-Bradley 1794-OB32P Flex I/O Output Module
- The module comes in an anti-static protective package.
- Standard packaging ensures safe transit and storage.
- We ship all orders via FedEx, UPS, and DHL.
- Choose express delivery for urgent replacement needs.
