Introduction
CtrlTechDaily reports that the Allen-Bradley 2094-BC07-M05-M is a new Kinetix 6000 Integrated Axis Module from Rockwell Automation. This module serves as a converter module for multi-axis motion control systems. It delivers robust power conversion and advanced safety features for demanding industrial applications. The 2094-BC07-M05-M helps manufacturers improve machine performance and reduce downtime.
Key Features
The 2094-BC07-M05-M integrates a converter and inverter in one unit. It provides a converter section output of 45 kW and an inverter section output of 49 A. This module accepts a nominal drive voltage of 360-480 Volts (3 Phase) with an input frequency of 47-63 Hz. The module also includes an internal shunt with continuous power of 200 Watts and peak power of 22.5 Watts. These features simplify system design and reduce cabinet space.
Advanced safety features protect personnel and equipment. The module includes Safe Speed, Safe Maximum Speed, Safe Maximum Acceleration Monitoring, Safe Direction Monitoring, Zero Speed Monitoring, Enabling Switch Control, and Door Monitoring and Control. Enhanced diagnostic features indicate the nature of faults. This helps operators quickly identify and resolve issues.
Technical Specifications
The 2094-BC07-M05-M operates with a voltage rating of 400/460VAC. Its power dissipation ranges from 71 to 226 Watts. The continuous output current to the bus is 67.7 A. The module has a maximum bus capacitance of 17,915 Microfarads. These specifications ensure stable power delivery for multi-axis systems.
The module measures 7.7 x 11.9 x 16.7 inches (196 x 302 x 426 mm) and weighs 22.0 lbs (9.98 kg). It requires an installation clearance of 80 mm (3.10 in.) and a minimum enclosure depth of 302 mm (11.9 in.). The operating temperature range is 32-122 F (0-50 C). Proper mounting and cooling ensure reliable operation.
Control input fuses include FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A). Control input breakers are 1492-SPM2D060 or 1492-SPM1D150. The DC bus power fuse is a Bussmann FWJ-125A or Mersen equivalent. These components protect the module and connected equipment.
Applications
The 2094-BC07-M05-M suits high-performance motion control applications. Typical uses include packaging machinery, material handling systems, assembly lines, and converting equipment. The module's modular design simplifies wiring and reduces spare parts inventory. It also allows easy modification with advancing technology.
In packaging, the module powers multiple servo axes for precise cut-to-length and registration control. In material handling, it drives conveyors and sortation systems with high dynamic response. The integrated safety features help meet industry safety standards without external safety relays.
Availability
The Allen-Bradley 2094-BC07-M05-M is available now through CtrlTechDaily. We maintain stock for quick shipment. Contact CtrlTechDaily for pricing and availability. Our team provides technical support and application assistance. We help you select the right components for your motion control system.
Frequently Asked Questions
What is the lead time for the 2094-BC07-M05-M?
CtrlTechDaily typically ships the 2094-BC07-M05-M within 24-48 hours for in-stock items. We maintain inventory to support urgent production needs. Contact our sales team for current lead times on larger quantities or special orders.
Does the 2094-BC07-M05-M come with a warranty?
Yes, the 2094-BC07-M05-M includes a standard Rockwell Automation warranty. The warranty covers defects in materials and workmanship. CtrlTechDaily provides support for warranty claims and replacement. Extended warranty options are available upon request.
What are the compatible systems for the 2094-BC07-M05-M?
The 2094-BC07-M05-M integrates with Kinetix 6000 drive systems and Allen-Bradley Logix controllers. It uses a common DC bus for shared power. The module supports velocity loop bandwidth of 500 Hz and current loop bandwidth of 1300 Hz. It communicates via the SERCOS interface. Compatibility with other systems requires verification of electrical and communication requirements.
