Introduction
CtrlTechDaily is pleased to offer the Bently Nevada 2300/20_KIT-002-00, a 2300/20 Condition Monitoring System Kit designed for industrial machinery protection and diagnostics. This kit provides a complete solution for monitoring vibration, speed, and process variables in critical rotating equipment. In this article, we explore the kit's core features, technical specifications, and its role in modern industrial automation.
Key Information
The 2300/20_KIT-002-00 includes one 2300/20 or 2300/25 monitor, one accelerometer sensor (AM3100T2-Z2), a 17 ft. (5.2 m) cable, and a housing kit. It supports ICP accelerometers, Velomitor, and Proximitor transducers, with configurable bandpass filters from 0.2 Hz to 20 kHz. The monitor features independent 24-bit ADCs on input channels for high-accuracy measurements. It also includes three buffered outputs (two vibration, one speed) via BNC connectors and two 4-20 mA outputs with internal current loop power supply.
Details and Analysis
The 2300/20_KIT-002-00 operates on a DC input of 18~36 Vdc with a maximum power consumption of 7.5 W. It supports multiple channel types, including accelerometers with a scale factor range of 5 to 1000 mV/g and a full scale range of 2 to 80 g peak. For radial vibration, the scale factor range is 5 to 1000 mV/mil with a full scale range of 0 to 160 mil peak-peak. The monitor also includes a speed/Keyphasor input supporting up to 20 kHz, with a threshold voltage resolution of 0.1 Vdc. These specifications ensure precise monitoring of machinery health in demanding environments.
Applications and Impact
This condition monitoring system kit is ideal for industries such as oil and gas, power generation, and manufacturing, where rotating machinery like pumps, compressors, and turbines require continuous vibration and speed monitoring. The kit's ability to store up to at least 5 alarm data captures during network disruptions ensures data integrity. Its operating temperature range of -30°C to +65°C and humidity tolerance up to 95% non-condensing make it suitable for harsh industrial environments. The kit also supports Ethernet communication (10Base-T and 100Base-TX) for seamless integration with System 1 software.
Conclusion
The Bently Nevada 2300/20_KIT-002-00 offers a robust, all-in-one solution for condition monitoring, combining high-accuracy sensors, flexible configuration, and reliable data storage. Contact CtrlTechDaily for pricing and availability. We provide fast shipping and expert technical support to help you implement this system in your facility.
Frequently Asked Questions
What makes the 2300/20_KIT-002-00 suitable for this topic?
This kit is designed for comprehensive condition monitoring, featuring configurable bandpass filters, multiple channel types, and Ethernet connectivity. It supports a wide range of transducers and provides accurate measurements for vibration, speed, and process variables, making it ideal for predictive maintenance in industrial settings.
What are the key specifications of the 2300/20_KIT-002-00?
Key specifications include a DC input of 18~36 Vdc, 7.5 W max power, configurable bandpass filters from 0.2 Hz to 20 kHz, scale factor ranges of 5 to 1000 mV/g for accelerometers and 5 to 1000 mV/mil for radial vibration, and an operating temperature range of -30°C to +65°C. The monitor also includes two 4-20 mA outputs and three buffered outputs.
How can I get more information about the 2300/20_KIT-002-00?
For detailed inquiries, pricing, and availability, contact CtrlTechDaily's sales and support team. We offer fast shipping and technical assistance to help you integrate this condition monitoring system into your operations.
