Product Summary
The Bently Nevada 9200-03-24-10-00 is a two-wire velocity seismoprobe transducer designed for precise casing vibration monitoring. It delivers a sensitivity of 20 mV/mm/s ±5% with a 4.5 Hz minimum operating frequency. This model includes a 24-foot cable, a circular M10x1 stud mount, and is dust and moisture resistant. Ideal for industrial rotating machinery protection.
Expert Technical Evaluation & Performance Review
Sensitivity and Calibration Accuracy
This transducer outputs 20 mV/mm/s (500 mV/in/s) when terminated with a 10 kΩ load and oriented at the calibration angle. The ±5% tolerance ensures reliable data for trend analysis. You can trust this sensor for consistent vibration readings across operating conditions.
Frequency Response and Dynamic Range
The 4.5 Hz (270 cpm) minimum operating frequency suits low-speed machinery. The dynamic operating range allows up to 2.54 mm peak-to-peak displacement. Velocity range reaches 25 mm/s at 100 Hz with a 10 kΩ load. This covers most industrial vibration monitoring needs.
Environmental Robustness and Material Quality
Operating temperature spans from -29°C to +121°C, suitable for harsh environments. The anodized aluminum case resists corrosion. Neoprene gasket provides reliable sealing against dust and moisture. Relative humidity tolerance reaches 95% noncondensing, or 100% non-submerged when ordered with integral cable.
Electrical Parameters and Signal Integrity
Coil resistance is 1.25 kΩ ±5% with typical locked coil inductance of 125 mH. The sensitivity temperature coefficient is only 0.2%/°C, minimizing drift. Output taken across pins A and B ensures clean signal transmission.
Product Procurement & Buyer Guide
Matching the Right Specifications
Selecting the 9200-03-24-10-00 requires understanding your mounting angle and cable length needs. Option 03 specifies a 90° mounting angle with a 4.5 Hz frequency floor. The connector option 24 gives you a 24-foot integral cable. Mounting base option 10 uses a circular M10x1 stud for secure attachment.
Application Engineering Considerations
Use this transducer for seismic velocity measurements on pumps, fans, and compressors. The two-wire design simplifies wiring to your monitoring system. Ensure the cable length matches your installation distance to avoid signal degradation. The robust aluminum case allows direct mounting on vibrating surfaces.
Factory Warranty and Authenticity Assurance
Every unit ships new and in original factory packing. You receive a full 12-month factory warranty. This ensures genuine Bently Nevada quality and traceability for your critical asset protection program.
Logistics & Standard Packaging Details
- One Bently Nevada 9200-03-24-10-00 two-wire velocity seismoprobe transducer
- Pre-attached 24-foot integral cable with connector
- Circular M10x1 mounting stud base
- Neoprene gasket for environmental sealing
- Calibration certificate and data sheet
- Express delivery shipping is available via FedEx, UPS, and DHL
