Product Summary
The Emerson SE4003S2B11 Analog Input Plus Card delivers 16 channels of precise 4-20 mA signal processing for your DeltaV DCS. This module supports HART communication and uses a 48-pin mass terminal block. It integrates seamlessly with P+F HiC barriers and termination boards for reliable field connectivity.
Theme Option A: Product Procurement & Buyer Guide
Simplify Your DeltaV System Integration
The SE4003S2B11 fits directly into any of the 64 available I/O slots. This flexibility allows for easy system expansion without rewiring. You can remove the module without disconnecting any field wires. This design drastically reduces installation time and expense for your project.
Key Specifications for Application Engineers
This card provides a full signal range of 2 to 22 mA. It achieves an accuracy of 0.2% of span over temperature. The 16-bit A/D converter ensures high-resolution signal capture. You get reliable data for critical process control loops in your plant.
HART Communication for Asset Management
The SE4003S2B11 supports HART pass-through for AMS Device Manager. It reports HART variables and status for control functions. The typical HART scan time is 600 to 800 ms per enabled channel. This feature gives you deep insight into your field device health.
Power and Isolation Specifications
The module requires a field circuit power of 500 mA maximum at 24V DC. Each channel is optically isolated and tested to 1000V DC. This isolation protects your system from ground loops and surges. It ensures safe operation in harsh industrial environments.
Redundancy for Critical Applications
You can configure the SE4003S2B11 for 1:1 redundancy with traditional I/O. In redundant mode, the local bus current is 110 mA typical. This setup provides uninterrupted process control if a card fails. It is a smart choice for your most important loops.
Why Choose the Plus Card Variant
The Plus Card supports both 2-wire and 4-wire transmitter configurations. It provides a minimum transmitter power of 13.5V at 20 mA. This power allows you to drive longer cable runs without signal loss. It gives you more flexibility in your field wiring design.
Logistics & Standard Packaging Details
- One Emerson DeltaV S-series SE4003S2B11 Analog Input Plus Card
- Product is individually packaged in an anti-static bag for safe transit
- Original Emerson packaging with model and serial number labels
- Express delivery shipping is available via FedEx, UPS, and DHL
