Product Summary
The 1734-IB8SK is a rugged safety input module from Rockwell Automation. It features eight sinking discrete channels for monitoring safety devices. This module includes a protective conformal coating for harsh environments. It meets strict SIL 3 and Category 4 safety standards. Engineers use it with GuardLogix and Compact GuardLogix controllers.
Theme A: Product Procurement & Buyer Guide
The 1734-IB8SK provides a critical function for machine safety systems. It monitors eight safety devices like e-stops and light curtains. This module supports a sinking input configuration for flexible wiring. It operates on an input voltage range of 18 to 30 VDC. The module ensures a fast input reaction time under 16.2 milliseconds. This speed is vital for quick system shutdown in emergencies.
Procurement managers must verify the module’s safety compliance level. This unit achieves a safety level of SIL 3 and Category 4. It also meets Performance Level e (PL e) requirements. The conformal coating protects against moisture and corrosive gases. This makes the module suitable for food processing or chemical plants. You can connect it to GuardLogix, Compact GuardLogix, or Smart Guard controllers.
The module includes four current sourcing Pulse Test outputs. These outputs work with sources T0, T1M, T2, and T3M. Each channel can source up to 0.7 Amps of current. The total output current is 2.8 Amps at 40 degrees Celsius. This feature allows the module to perform diagnostic testing on sensors. It helps detect wiring faults before they cause a hazard.
Theme D: Expert Technical Evaluation & Performance Review
This input module uses a Type 3 design per IEC 61131-2 standards. The minimum on-state current is 3.3 milliamps for reliable detection. The maximum off-state current is 1.3 milliamps to prevent false signals. This high noise immunity ensures stable operation in industrial settings. The module supports both single and dual channel operation modes. You can configure the on and off delay settings individually.
The 1734-IB8SK receives power directly from the system backplane. It can also use a separate field bus power supply if needed. The terminal base uses an 8-point connection for secure wiring. The module’s conformal coating is a key feature for longevity. This coating protects sensitive electronics from condensation and chemical exposure. It significantly extends the module’s life in harsh environments.
The pulse test outputs provide a major diagnostic advantage. They allow the system to check sensor wiring integrity continuously. This reduces the risk of undetected failures in safety circuits. The module distributes safety I/O across the network efficiently. It works seamlessly within the POINT Guard I/O system architecture. This integration simplifies system design and reduces panel space.
Logistics & Standard Packaging Details
- One (1) Allen-Bradley 1734-IB8SK safety input module
- The module includes factory-installed conformal coating
- Standard retail packaging ensures safe transport
We offer express delivery shipping for this product. You can choose FedEx, UPS, and DHL for fast transit. Contact our sales team for specific shipping lead times.
