Product Summary
The Allen-Bradley 1734-IE2V is a compact POINT I/O analog input module. It provides two single-ended voltage channels for precise signal acquisition. This module uses a Delta Sigma converter for high accuracy. It is an ideal solution for remote I/O applications requiring small to medium input counts.
Expert Technical Evaluation & Performance Review
The 1734-IE2V delivers exceptional signal fidelity for industrial control systems. Its core strength lies in the Delta Sigma conversion type. This method provides high-resolution, noise-immune data for critical processes.
The module accepts a user-configurable input signal range. You can set it for 0...10V or ±10V operation. The absolute accuracy is rated at 0.1% Full Scale @ 25 °C. This ensures reliable measurement for variables like pressure or flow.
The module converts analog signals into a 16-Bit signed integer. This data format ranges from -32,768 to +32,767. It generates six bytes of data per cycle. This includes channel data and status information for both inputs.
Engineers will appreciate the configurable latching alarms. You can set high, high-high, low, and low-low thresholds. This feature allows for proactive process monitoring. You can also disable alarms to suit specific application needs.
The module’s input rate is adjustable. This allows it to match process characteristics. You can optimize it for slow, medium, or fast-changing signals. This flexibility is vital for fluctuating or stable process variables.
The 1734-IE2V operates on a DC voltage range from 12 to 24 Volts. Its power dissipation is only 0.75 Watts at 28.8 Volts DC. This low thermal output simplifies cabinet cooling requirements.
Step-by-Step Installation & User Guide
Proper installation ensures reliable operation and long service life. Follow these steps to deploy the 1734-IE2V module correctly.
First, mount the module on a standard DIN rail. The POINT I/O family uses a compact form factor. Ensure the rail is securely grounded.
Next, set the key switch to position 3. This mechanical feature prevents incorrect module insertion. It is a critical step for system integrity.
Then, connect the field wiring to the terminal base. The module has two single-ended, non-isolated inputs. Use the correct wiring diagram for your voltage signal type.
Apply power to the module. The front panel status indicators will illuminate. A steady green light confirms normal operation.
Configure the module using your control software. Set the input range to either 0...10V or ±10V. Adjust the input filter rate to match your process signal.
Finally, verify the data format. The module outputs a signed integer value. Check that the scaling matches your application requirements.
Logistics & Standard Packaging Details
- 1x Allen-Bradley 1734-IE2V Analog Input Module
- 1x Key Switch Assembly (pre-installed)
- 1x Product Documentation Leaflet
We ship all orders via express delivery services. Your module will arrive quickly through FedEx, UPS, and DHL. This ensures minimal downtime for your project.
