Product Summary
The Allen-Bradley 1762-L24AWA is a powerful MicroLogix 1200 Programmable Logic Controller. This unit integrates fourteen 120VAC inputs with ten relay outputs. It provides a robust solution for demanding industrial automation tasks. The controller operates on a 120/240VAC supply voltage. Its embedded communication port supports DF1, DH-485, ASCII, and MODBUS protocols. This makes the 1762-L24AWA a versatile choice for system integration.
Theme Option A: Product Procurement & Buyer Guide
Procurement managers need a controller that delivers reliable performance. The 1762-L24AWA meets this need with its rugged design. It operates in temperatures from 0 to 55 degrees Celsius. This ensures stable function in typical industrial environments. The unit also withstands operational vibration of 1.5G. This makes it suitable for applications near heavy machinery.
Application engineers will value the flexible I/O configuration. The controller has fourteen 120VAC digital inputs for sensor signals. It also provides ten relay outputs for actuator control. Each relay contact handles up to 240VAC at 10A. This allows direct control of motors, valves, and solenoids. The relay outputs offer 20 million mechanical cycles for long life.
The communication port supports multiple industrial protocols. Engineers can integrate the 1762-L24AWA into existing networks easily. DF1 and DH-485 are common for Rockwell Automation systems. ASCII and MODBUS allow connection to third-party devices. This flexibility reduces the need for additional communication modules.
This controller simplifies the supply chain for many facilities. It combines the power supply, processor, and I/O into one unit. This reduces the number of components to source and stock. The compact dimensions of 90 x 160 x 87 mm save panel space. Its lightweight design at just 2.0 pounds simplifies shipping and handling.
Theme Option D: Expert Technical Evaluation & Performance Review
The 1762-L24AWA delivers precise and reliable signal processing. Its digital inputs have a clear ON-state voltage range. The inputs recognize an ON state from 79 to 132 Volts AC. They see an OFF state from 0 to 20 Volts AC. This wide voltage margin prevents false readings from noise. The ON-state current ranges from 5 mA to 16 mA. This provides consistent detection across various sensor types.
The relay outputs offer excellent switching performance. They have a maximum load control of 1440 VA. Each output group supports an 8A load current. The entire controller can handle a 30A load at 150 Volts AC. The relay ON/OFF time is just 10ms for fast response. This speed is critical for precise machine control sequences.
Environmental tolerances are a key strength of this unit. It operates in humidity from 5% to 95% non-condensing. This makes it suitable for humid plant floors. The storage temperature range is very wide. It can survive storage from -40 to 85 degrees Celsius. This protects the unit during transport in extreme climates.
The controller meets rigorous safety and quality standards. It holds UL, c-UL, and CE certifications. This ensures compliance with North American and European regulations. The unit is designed for Over Voltage Category II circuits. This protects the controller from typical industrial power surges. Its 15G operational shock rating ensures durability during use.
Logistics & Standard Packaging Details
- One (1) Allen-Bradley MicroLogix 1200 1762-L24AWA Programmable Controller
- One (1) Product Documentation Quick Reference Guide
- One (1) Removable I/O Terminal Block Connector Set
Express delivery shipping is available for this item. We ship via FedEx, UPS, and DHL to meet your deadlines. Contact our sales team for current stock levels and lead times.
