Introduction
CtrlTechDaily reports that the Allen-Bradley 2097-V34PR6-LM is now available as a Kinetix 300 Ethernet I/P single-axis servo drive. This drive operates on a 320-528V rms three-phase input with a nominal rating of 480V. It delivers 3.0 kW of continuous power, making it a robust solution for precise motion control in industrial automation.
The 2097-V34PR6-LM integrates seamlessly into modern manufacturing systems. Its compact design and advanced features address the growing demand for high-performance servo drives in smart factories.
Key Features
The 2097-V34PR6-LM offers a continuous output current of 6.0 A rms and a peak output current of 18.0 A rms. This allows it to handle demanding applications with high torque requirements. The drive also includes Safe Torque-Off functionality, which enhances operator safety by disabling the motor drive power without removing power from the drive itself.
Another key feature is its integrated motion control over EtherNet/IP. This simplifies system architecture and reduces wiring costs. The drive supports a control power back-up input voltage of 20-26V DC, ensuring reliable operation during power fluctuations.
Technical Specifications
The drive's input frequency range is 48-62 Hz, accommodating global power standards. Its main AC input current is 7.9 A nominal rms, with a peak of 22.6 A. The continuous power output is 3.00 kW, and the power rating is 3.0 kWatts. These specifications make the 2097-V34PR6-LM suitable for medium-power servo applications.
The drive measures 9.37 x 7.29 x 3.06 inches (238 x 185.1 x 12.38 mm) and weighs 4.0 lbs (1.8 kg). Its compact footprint allows for easy integration into existing control cabinets. The drive does not include an integrated AC (EMC) line filter, so external filtering may be required for compliance.
Applications
The 2097-V34PR6-LM is ideal for packaging machinery, where precise speed and position control are critical. It also excels in material handling systems, such as conveyors and sorters, where its peak current capability ensures smooth acceleration and deceleration. Assembly lines benefit from its Safe Torque-Off feature, which protects operators during maintenance.
In process control applications, the drive's EtherNet/IP connectivity enables seamless integration with PLCs and HMIs. This reduces commissioning time and improves overall system efficiency.
Availability
The Allen-Bradley 2097-V34PR6-LM is in stock at CtrlTechDaily. We offer fast shipping and comprehensive technical support. Contact CtrlTechDaily for pricing and availability. Our team can help you select the right drive for your application and provide integration guidance.
Frequently Asked Questions
What is the lead time for the 2097-V34PR6-LM?
Lead time is typically 2-4 weeks, depending on order volume. CtrlTechDaily maintains inventory to ensure quick delivery for most orders. Contact our sales team for current stock levels and expedited shipping options.
Does the 2097-V34PR6-LM come with a warranty?
Yes, the drive comes with a standard manufacturer warranty from Rockwell Automation. CtrlTechDaily also offers extended warranty options and after-sales support. Contact us for detailed warranty terms and conditions.
What are the compatible systems for the 2097-V34PR6-LM?
The drive is compatible with Allen-Bradley ControlLogix and CompactLogix controllers via EtherNet/IP. It also works with other Rockwell Automation motion control systems. The drive requires a 320-528V rms three-phase power supply and supports Safe Torque-Off integration with safety relays or safety PLCs.
