Introduction
CtrlTechDaily reports that the Allen-Bradley 2097-V34PR6 Kinetix 300 EtherNet/IP Indexing Servo Drive is now available for industrial automation applications. This drive belongs to the 2097 series from Rockwell Automation and provides precise motion control over EtherNet/IP networks. It supports seamless integration with MicroLogix 1400, CompactLogix, and ControlLogix controllers, making it a versatile choice for modern manufacturing lines.
Key Features
The 2097-V34PR6 delivers a continuous power output of 3.00 kW and a continuous output current of 6.0 A (rms) or 8.5 A (0-pk). Its peak output current reaches 18.0 A (rms) and 25.5 A (0-pk), enabling high-torque applications. The drive includes Safe Torque-Off functionality, which enhances operator safety during maintenance and emergency stops.
This drive operates on a three-phase input voltage of 320-528V rms with a nominal 480V supply. It accepts input frequencies from 48 to 62 Hz and has a main AC input current of 7.9 A (nominal rms). The integrated control power back-up input accepts 20…26V DC at 500 mA nominal, with a maximum inrush of 30 A. These specifications ensure reliable performance in demanding industrial environments.
Technical Specifications
The 2097-V34PR6 dissipates 99 Watts of power and operates within a temperature range of 32-104 F (0-40 C). Its dimensions are 9.37 x 9.04 x 2.68 inches (238 x 230 x 68.0 mm), and it weighs 4.0 lbs (1.8 kg). The drive supports a torque value of 5.0-7.0 lb*in (0.56-0.79 N*m) and does not include an integrated AC line filter or 120 Volt Doubler Mode.
For UL applications, install appropriate line protection devices such as a Bussmann fuse (catalog KTK-R-10, 10A), a miniature circuit breaker (1489-M3C100), or a self-protected CMC motor protection CB (140M-C2E-C10). The drive requires a 480V AC Class CC and Class T current-limiting Bussman fuse and uses a 480V (140M-F8E-C20) fully-rated circuit breaker for short-circuit protection.
Applications
The 2097-V34PR6 excels in packaging, material handling, and assembly line applications where precise indexing and positioning are critical. It works with Kinetix MP and TLY Rotary Motors, Kinetix MPAI Heavy-duty Electric Cylinders, MPAR Electric Cylinders, LDAT-Series Linear Thrusters, LDC-Series Linear Motors, LDL-Series Linear Motors, and Kinetix MPAS Integrated Linear Stages. This compatibility allows engineers to build flexible, high-performance motion systems.
In packaging lines, the drive controls servo motors for precise cut-to-length, labeling, and filling operations. In material handling, it manages conveyor indexing and robotic pick-and-place tasks. Assembly lines benefit from its ability to synchronize multiple axes for complex assembly sequences.
Availability
The Allen-Bradley 2097-V34PR6 is in stock at CtrlTechDaily with fast shipping options. Contact CtrlTechDaily for pricing, lead times, and technical support. Our team provides pre-sales consultation, installation guidance, and after-sales service to ensure successful deployment.
Frequently Asked Questions
What is the lead time for the 2097-V34PR6?
CtrlTechDaily maintains inventory of the 2097-V34PR6, allowing for short lead times. Standard orders ship within 1-2 business days. For bulk or urgent requirements, contact our sales team for expedited options.
Does the 2097-V34PR6 come with a warranty?
Yes, the 2097-V34PR6 includes a manufacturer warranty from Rockwell Automation. CtrlTechDaily provides additional support for warranty claims and technical issues. Contact our support team for specific warranty terms and coverage details.
What are the compatible systems for the 2097-V34PR6?
The 2097-V34PR6 integrates with MicroLogix 1400, CompactLogix, and ControlLogix controllers over EtherNet/IP. It works with Kinetix MP and TLY Rotary Motors, MPAI and MPAR Electric Cylinders, LDAT Linear Thrusters, LDC and LDL Linear Motors, and MPAS Integrated Linear Stages. The drive supports I/O expansion via its 50-pin IOD connector and requires an EEPROM module for configuration backup.
