Introduction
CtrlTechDaily reports that the Allen-Bradley 2094-BC01-MP5-S is now available as a key component of the Kinetix 6000 Motion control system. This 400 Volt class Integrated Axis Module (IAM) delivers robust performance for multi-axis servo drive applications. The module supports high-efficiency motion control with integrated safety features.
Key Features
The 2094-BC01-MP5-S operates at an AC input voltage range of 324-528 Volts rms, 3-Phase, with a nominal input of 360/480 VAC. It delivers a continuous output power to bus of 6 kW and a continuous output current to bus of 9.0 Amperes. The module achieves 97% efficiency, reducing energy waste and heat generation.
Integrated Safe Torque Off (STO) functionality enhances operator safety by disabling drive torque without removing power. This feature meets modern safety standards and simplifies machine design. The module also supports common-bus follower operation with a DC input voltage range of 458-747 Volts DC.
Technical Specifications
The 2094-BC01-MP5-S accepts AC input frequencies from 47 to 63 Hertz. Its nominal RMS AC input current is 10.0 Amperes, with a maximum inrush current of 11.0 Amperes. The module includes an internal shunt with continuous power of 50 Watts and peak power of 5.6 Kilowatts, using a 115 Ohm resistor.
Weight is 11.0 lbs (4.98 kg), and installation requires a clearance of 50.8 mm (2.0 in.) with a minimum enclosure depth of 198 mm (7.8 in.). The module mounts on a Power Rail within the Kinetix 6000 system. Bus overvoltage protection is set at 425V DC, and bus undervoltage at 275V DC.
Applications
The 2094-BC01-MP5-S suits high-performance motion control in packaging, material handling, and assembly lines. It integrates with Allen-Bradley ControlLogix PACs via SERCOS communication. The module supports various servo motors including Kinetix MP, TL/TLY, and F-Series, as well as linear actuators.
In packaging applications, the module provides precise speed and position control for wrapping, filling, and labeling machines. For material handling, it enables synchronized motion in conveyors and robotic pick-and-place systems. The integrated STO function reduces wiring complexity and improves safety in automated cells.
Availability
CtrlTechDaily offers the Allen-Bradley 2094-BC01-MP5-S with fast shipping and comprehensive technical support. Contact CtrlTechDaily for pricing and availability. Our team provides pre-sales consultation and after-sales service to ensure successful integration.
Frequently Asked Questions
What is the lead time for the 2094-BC01-MP5-S?
CtrlTechDaily maintains inventory of the 2094-BC01-MP5-S to ensure short lead times. Typical delivery occurs within a few business days. Contact our sales team for current stock levels and expedited shipping options.
Does the 2094-BC01-MP5-S come with a warranty?
Yes, the Allen-Bradley 2094-BC01-MP5-S includes a manufacturer warranty from Rockwell Automation. CtrlTechDaily provides additional support for warranty claims and technical issues. Our team helps with RMA processes and replacement units.
What are the compatible systems for the 2094-BC01-MP5-S?
The 2094-BC01-MP5-S integrates with ControlLogix PACs using a 1756-M0xSE SERCOS interface module. It mounts on a Kinetix 6000 Power Rail alongside Axis modules and Shunt modules. The module supports Kinetix MP, TL/TLY, RDB, 1326AB, and F-Series servo motors, plus LDAT-Series and LDC-Series linear actuators.
