Product Summary
The Allen-Bradley 170ADO35000 is a high-performance POINT I/O output module designed for precise industrial control applications. It delivers 16 discrete output points with 24V DC operation and 0.5 amps per point for reliable actuator and indicator control.
Core Technical Specifications & Parameters
The 170ADO35000 output module provides sixteen discrete sourcing output channels operating at a nominal voltage of 24V DC. Each output point delivers a maximum continuous current of 0.5 amps with a total module current limit of 8 amps. The module features an on-state voltage drop of less than 1.5V DC at rated current for efficient power delivery. Outputs are protected against short circuits with automatic reset functionality to enhance system reliability. The module operates within an ambient temperature range of -20°C to +60°C for versatile industrial deployment. It offers a maximum off-state leakage current of 0.5 milliamps to prevent false triggering of connected loads. The module provides optical isolation of 1500V AC between field wiring and system logic for robust noise immunity. Each output point includes individual LED indicators for immediate visual status confirmation during operation.
Professional Installation & Wiring Guidelines
Begin installation by mounting the 170ADO35000 module onto a standard POINT I/O terminal base unit until it clicks securely into place. Connect the 24V DC power supply to the module bus using the designated power terminals on the base assembly. Wire each output load to the corresponding screw terminal using copper wire rated for at least 75°C. Ensure all field wiring is properly terminated with a torque specification of 0.5 to 0.6 Newton-meters for reliable electrical connections. Verify that the total current draw from all active outputs does not exceed the module's 8 amp aggregate limit. Apply power to the system and confirm that the module status LED illuminates green to indicate normal operation. Test each output channel individually by energizing the corresponding bit through the control program.
Standard Packaging List & Logistics
- One Allen-Bradley 170ADO35000 POINT I/O output module
- Product documentation and installation instructions sheet
- Removable terminal block for field wiring connections
- Module identification label for panel organization
Express delivery shipping is available via FedEx, UPS, and DHL for rapid deployment to your facility.
Frequently Asked Questions (FAQ)
What is the maximum load current per output point on the 170ADO35000 module?
Each output point on this module can handle a maximum continuous current of 0.5 amps at 24V DC.
Can the 170ADO35000 module be used with 120V AC loads?
No, this module is designed exclusively for 24V DC loads and cannot operate with AC voltages.
How do I replace a blown fuse on this output module?
This module uses electronic short circuit protection with automatic reset and does not contain replaceable fuses.
What is the minimum load current required for reliable operation?
The module requires a minimum load current of 1 milliamp per output point for proper switching operation.
Does the module support sinking or sourcing output configuration?
The 170ADO35000 is a sourcing output module that provides positive voltage to the connected load.
