Product Summary
This Bently Nevada 9200-01-01-10-00 is a robust two-wire velocity seismoprobe transducer designed for precise industrial vibration monitoring. It delivers reliable performance in harsh environments with a standard sensitivity of 20 mV/mm/s for accurate machinery protection.
Core Technical Specifications & Parameters
The Bently Nevada 9200-01-01-10-00 is a high-performance two-wire velocity seismoprobe transducer engineered for continuous vibration monitoring. This model features a transducer mounting angle of 0 ±2.5 degrees with a minimum operating frequency of 4.5 Hz (270 cpm). The unit provides a standard sensitivity of 20 mV/mm/s (500 mV/in/s) with a ±5% tolerance when properly terminated and oriented at the calibration angle. Its dynamic operating range allows for a maximum displacement of 2.54 mm (0.100 in) peak to peak. The velocity range is 25 mm/s (1 in/s) at +22 °C of casing vibration measured at 100 Hz with a 10 kΩ load. The coil resistance is 1.25 kΩ ±5% with a typical locked coil inductance of 125 mH. This transducer operates reliably across a temperature range of -29°C to +121°C (-20°F to +250°F) and can withstand relative humidity up to 95% noncondensing. The case and adapter are constructed from anodized aluminum A204 with a neoprene gasket for dust and moisture resistance.
Professional Installation & Wiring Guidelines
Begin the installation process by selecting a clean and flat mounting surface on the machinery casing. Secure the transducer using the circular M10X1 stud mounting base option with appropriate torque specifications. Ensure the transducer is oriented at the correct angle of 0 ±2.5 degrees for optimal performance. Connect the output across terminal A and terminal B using a 10 kΩ calibration load for accurate signal measurement. Verify that the cable connections are properly terminated to avoid signal degradation or noise interference. Always confirm that the operating environment stays within the specified temperature and humidity limits to maintain measurement integrity.
Standard Packaging List & Logistics
- One Bently Nevada 9200-01-01-10-00 Two-Wire Velocity Seismoprobe Transducer
- Top mount connector option with no cable included
- Circular M10X1 stud mounting base for secure attachment
- Factory-sealed packaging to ensure product integrity during transit
- Express delivery shipping is available via FedEx, UPS, and DHL
Frequently Asked Questions (FAQ)
Q: What is the standard sensitivity of the 9200-01-01-10-00 transducer?
A: The standard sensitivity is 20 mV/mm/s (500 mV/in/s) with a ±5% tolerance when properly terminated and oriented at the calibration angle.
Q: What is the maximum operating temperature for this transducer model?
A: The 9200-01-01-10-00 operates reliably within a temperature range of -29°C to +121°C (-20°F to +250°F).
Q: How should I connect the output wires for this two-wire transducer?
A: Connect the output across terminal A and terminal B using a 10 kΩ calibration load for accurate signal measurement.
Q: What mounting base option is included with this specific model?
A: This model includes the circular M10X1 stud mounting base option for secure attachment to machinery casings.
Q: Can this transducer be used in high humidity environments?
A: Yes, it can withstand relative humidity up to 95% noncondensing and is dust and moisture resistant.
