KL4101X1-BA1 CHARM I/O Card Carrier for Hazardous Zones
Product Summary
The KL4101X1-BA1 is a rugged CHARM I/O Card Carrier designed for hazardous environments. This unit powers up to 12 CHARMS with a robust 24 VDC supply. It operates reliably from -40 °C to +70 °C. Engineers trust this carrier for its global safety certifications and Class G3 contaminant resistance.
Theme: Product Procurement & Buyer Guide
Understanding Your Hazardous Area Requirements
Procurement managers must verify the area classification before ordering. The KL4101X1-BA1 carries approvals for Zone 2 and Division 2 locations. It holds certifications like FM19ATEX0173U and IECEx FMG 19.0019U. These marks confirm compliance with II 3G Ex ec IIC Gc standards. You can deploy this carrier safely in gas groups A, B, C, and D. Always confirm your local regulations match these global certifications.
Power Supply Specifications for System Design
This carrier requires a specific power input to function correctly. You must supply 24 VDC at 12 A to the main input. The unit then delivers 6.3 VDC at 3.25A to power the attached CHARMS. This regulated output ensures each I/O module receives stable energy. Design your system power budget to accommodate these exact values. Failure to match these specs will cause operational failures.

Environmental Tolerances for Industrial Applications
The KL4101X1-BA1 withstands extreme industrial conditions without performance loss. It operates within an ambient temperature range of -40 °C to +70 °C. The unit handles shock loads of 10g for 11 milliseconds. It also resists vibration from 2 to 150 Hz effectively. The carrier meets ISA-S71.04 Class G3 for airborne contaminants. These features make it ideal for harsh chemical plants and refineries.
Installation and Safety Protocols
You cannot remove or insert this unit with power applied. This rule only changes if the area is confirmed non-hazardous. Always de-energize the system before handling the carrier. The unit contains no user-serviceable parts inside its chassis. Do not disassemble the housing for any maintenance reason. The device does not require any field calibration.
Logistics & Standard Packaging Details

- One KL4101X1-BA1 CHARM I/O Card Carrier unit
- Mounting hardware kit for secure panel installation
- Product documentation and certification sheet
- Anti-static packaging for safe transit
- Express shipping options via FedEx, UPS, and DHL

Theme: Step-by-Step User & Installation Guide
Preparing for Mechanical Mounting
Begin by selecting a clean, dry mounting surface for the carrier. Ensure the location is within the specified temperature range. Use the provided hardware to secure the unit firmly. The carrier design allows for easy DIN rail or panel mounting. Verify the orientation allows proper airflow for cooling. Double-check that the area classification matches the unit's certifications.
Connecting the Main Power Input
Supply a dedicated 24 VDC power source rated for 12 amps. Connect the positive lead to the designated input terminal. Connect the negative lead to the common return terminal. Ensure all connections are tight and secure before powering on. Do not apply power until all CHARMS are installed. Use wire gauges suitable for a 12-amp continuous load.
Installing the CHARM I/O Modules
Insert each CHARM module into its designated slot on the carrier. Press firmly until the module clicks into place. The carrier supports up to 12 CHARMS simultaneously. Verify each module is seated correctly before applying power. The output to CHARMS is fixed at 6.3 VDC. This low voltage ensures safe operation in hazardous areas.
Final System Power-Up Sequence
Confirm the area is non-hazardous before proceeding with power-up. Apply the 24 VDC input power to the carrier terminals. Observe the status indicators for normal operation. The carrier will distribute power to all installed CHARMS. If the system fails to power, check all connections again. Never operate the unit with damaged cables or connectors.
